Manual aluminum spot welding controller adopts three-phase sine wave AC input, after rectification, filtering, inverter, output 1000Hz or 1800Hz square wave AC, and then input to medium frequency DC welding gun, through DC transformer diode rectified output smooth and stable DC, to meet welding needs of different workpieces. The welding controller has a variety of specifications for customers to choose according to welding needs, time accuracy is millisecond, output current accuracy is ≤±3%. Can be placed on steel platform or suspended under steel structure according to customer requirements.
It has 256 sets of welding speciflcations
The constant phase Angle(PHA);Constant current control mode(KSR)
It has adaptive function
Reserved networking function
Communication mode I/O
There are two cooling methods water cooling and air cooling
Handheld programming and computer software programming
Input voltage: AC3~380V , 50Hz/60Hz;Power fluctuation+ 10%, -20%
Output voltage: PWM 500V
Output frequency:1000Hz
Environment temperature:0~50°C
Humidity:≤90%,no condensation
Output current:600A(X=10% )
Valve specification:DC24V
